ESD Conductive Sponge Foam Gasket for EMI Shielding With Pressure Sensitive Adhesive Die Cut Custom Electrical Grounding
ESD Conductive Sponge Foam Gasket for EMI Shielding With Pressure Sensitive Adhesive Die Cut Custom Electrical Grounding
ESD Conductive Sponge Foam Gasket for EMI Shielding With Pressure Sensitive Adhesive Die Cut Custom Electrical Grounding
ESD Conductive Sponge Foam Gasket for EMI Shielding With Pressure Sensitive Adhesive Die Cut Custom Electrical Grounding
ESD Conductive Sponge Foam Gasket for EMI Shielding With Pressure Sensitive Adhesive Die Cut Custom Electrical Grounding
ESD Conductive Sponge Foam Gasket for EMI Shielding With Pressure Sensitive Adhesive Die Cut Custom Electrical Grounding
ESD Conductive Sponge Foam Gasket for EMI Shielding With Pressure Sensitive Adhesive Die Cut Custom Electrical Grounding
ESD Conductive Sponge Foam Gasket for EMI Shielding With Pressure Sensitive Adhesive Die Cut Custom Electrical Grounding
ESD Conductive Sponge Foam Gasket for EMI Shielding With Pressure Sensitive Adhesive Die Cut Custom Electrical Grounding
ESD Conductive Sponge Foam Gasket for EMI Shielding With Pressure Sensitive Adhesive Die Cut Custom Electrical Grounding
ESD Conductive Sponge Foam Gasket for EMI Shielding With Pressure Sensitive Adhesive Die Cut Custom Electrical Grounding
ESD Conductive Sponge Foam Gasket for EMI Shielding With Pressure Sensitive Adhesive Die Cut Custom Electrical Grounding

ESD Conductive Sponge Foam Gasket for EMI Shielding With Pressure Sensitive Adhesive Die Cut Custom Electrical Grounding

Get a Quote

Introduction

Products Description

Johan ECF (Elastic Conductive Foam)

Semi-Fold(SF) series - Super Thin Space Grounding with low CFD and surface resistance

Technical Data Sheet

Updated: May,2021


Description
This grounding foam is made of high-rebound elastomer base and super thin conductive fabric or film and suitable for high
requirement grounding in super thin space. Due to its unique structure, it shows low electrical resistance and stable physical
properties even after tough environment test.

Structure


ESD Conductive Sponge Foam Gasket for EMI Shielding With Pressure Sensitive Adhesive Die Cut Custom Electrical Grounding supplier



Patent No: CN206619706U

Application

① RF Antenna Grounding（stable and low conductivity)
② LCD/OLED Grounding (Min CFD<[email protected] gap)
③ Replace shrapnel in super thin space grounding (Min Gap<=0.20mm)
④ Very small grounding area (Size<=5mmX5mm -resistance 90% lower than plating-conductive foam)
Typical Physical Properties
The following technical information and data should be considered representative or typical only and should not be used for
specification purposes.


Conductivity Performance (5mmX5mmX0.60mm with fabric-nickel-plating (0.032mm) sample)


Test Of Compression (Internal Method)
Compression Rate
0%
30%
50%
70%
Through-Resistance（Ω）
0.179
0.080
0.051
0.045


Test Of High Temperature and High Humidity (-20C to 80C with 85% RH @ 2hours/cycle * 12 cycles)
Compression Rate
0%
30%
50%
70%
Through-Resistance（Ω）
0.201
0.115
0.070
0.058


Base Material CFD Performance
ESD Conductive Sponge Foam Gasket for EMI Shielding With Pressure Sensitive Adhesive Die Cut Custom Electrical Grounding supplier
ESD Conductive Sponge Foam Gasket for EMI Shielding With Pressure Sensitive Adhesive Die Cut Custom Electrical Grounding manufacture
ESD Conductive Sponge Foam Gasket for EMI Shielding With Pressure Sensitive Adhesive Die Cut Custom Electrical Grounding supplier


Typical Dimension Table*
ESD Conductive Sponge Foam Gasket for EMI Shielding With Pressure Sensitive Adhesive Die Cut Custom Electrical Grounding factory

Other dimension could be customized per demand.

Standard Products for LCD/OLED application (2mmX8mmX0.60mm/0.85mm)
(Fabric/Film with Au-plating work better with high refresh rate display including LCD and provide more stable performance over time)
ESD Conductive Sponge Foam Gasket for EMI Shielding With Pressure Sensitive Adhesive Die Cut Custom Electrical Grounding details

(Working Height: 0.20mm ECF-SF-05S3 Fabric-Ni-Plating)


ESD Conductive Sponge Foam Gasket for EMI Shielding With Pressure Sensitive Adhesive Die Cut Custom Electrical Grounding supplier

(Working Height: 0.30mm ECF-SF-07S3 Fabric-Ni-Plating)


ESD Conductive Sponge Foam Gasket for EMI Shielding With Pressure Sensitive Adhesive Die Cut Custom Electrical Grounding supplier

(Working Height: 0.20mm ECF-SF-05S3GP Fabric-Au-Plating )


ESD Conductive Sponge Foam Gasket for EMI Shielding With Pressure Sensitive Adhesive Die Cut Custom Electrical Grounding manufacture

(Working Height: 0.33mm ECF-SF-07S3GP Fabric-Au-Plating)


— Electrical resistance —Rebound force


ESD Conductive Sponge Foam Gasket for EMI Shielding With Pressure Sensitive Adhesive Die Cut Custom Electrical Grounding manufacture

Our exhibition
Our company actively pursues global market expansion through strategic participation in premier international exhibitions including CES and Electronics China. We are aggressively penetrating diverse sectors such as consumer electronics, new energy vehicles, communication equipment, and emerging fields including AI and IoT. Having successfully commenced deliveries in these new domains, we maintain strong momentum in continuous exploration of additional overseas markets. Our dynamic approach demonstrates unwavering commitment to global business development and technological innovation.

Company Profile

Established in 2011, Shenzhen Johan Material Technology Co., Ltd. is a pioneering material company specializing in EMI/EMCsolutions. Our forte lies in the production of shielding and grounding gaskets and custom-designed, high-performance tapes. In 2022, we earned the prestigious national-level specialized and innovative small giant certification.

We cater primarily to the consumer electronics, communication networks, and emerging energy vehicle sectors. To back ourcommitment to quality and innovation, we have established a national production base across four strategic locations:

1. A 1,000-square-meter new material formula R&D center in Shenzhen.
2. A 2,000-square-meter innovative grounding wrapping production plant in Dongguan.
3. A 10,000-square-meter conductive shielding tape coating plant in Hunan.
4. A 1,000-square-meter magnetron sputtering continuous gold/tin plating plant in Shandong.

As the only vertically integrated integrator in China offering electroplating, coating, and processing capabilities, we strive to become a leading innovator and provider of core values within the materials industry chain. Our ultimate goal is to be a long-term trusted solution provider and partner for our customers in addressing their challenges.

System certification

Our company maintains a comprehensive quality management system, certified to ISO 9001:2015 (SGS) for quality assurance and IATF16949 (SGS) for automotive industry standards. We are also certified to ISO 14001 (SGS) for environmental management and QC 080000 (SGS) for hazardous substance process control. These certifications demonstrate our commitment to delivering reliable, high-quality products through systematic process control and continuous improvement.
ESD Conductive Sponge Foam Gasket for EMI Shielding With Pressure Sensitive Adhesive Die Cut Custom Electrical Grounding factory
ESD Conductive Sponge Foam Gasket for EMI Shielding With Pressure Sensitive Adhesive Die Cut Custom Electrical Grounding supplier
ESD Conductive Sponge Foam Gasket for EMI Shielding With Pressure Sensitive Adhesive Die Cut Custom Electrical Grounding supplier
ESD Conductive Sponge Foam Gasket for EMI Shielding With Pressure Sensitive Adhesive Die Cut Custom Electrical Grounding manufacture

Invention Patent

Based on our strong R&D capabilities, we possess 12 Chinese and 2 U.S. invention patents, plus 30 utility model patents. These patented technologies are applied across our core product lines, including innovative grounding foam and high-performance custom tapes, demonstrating our industry leadership in EMI/EMC materials and providing customers with reliable, proprietary solutions.
ESD Conductive Sponge Foam Gasket for EMI Shielding With Pressure Sensitive Adhesive Die Cut Custom Electrical Grounding details
ESD Conductive Sponge Foam Gasket for EMI Shielding With Pressure Sensitive Adhesive Die Cut Custom Electrical Grounding details
ESD Conductive Sponge Foam Gasket for EMI Shielding With Pressure Sensitive Adhesive Die Cut Custom Electrical Grounding factory
ESD Conductive Sponge Foam Gasket for EMI Shielding With Pressure Sensitive Adhesive Die Cut Custom Electrical Grounding details
ESD Conductive Sponge Foam Gasket for EMI Shielding With Pressure Sensitive Adhesive Die Cut Custom Electrical Grounding manufacture

FAQ

1. who are we?
We are based in Guangdong, China, start from 2011,sell to South Asia(10.00%). There are total about 101-200 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
Shielding tape,Adhesive tapes,Waterproof and breathable membrane,Customized production,Raw material die-cutting

4. why should you buy from us not from other suppliers?
Shenzhen Johan Material Tech Co., Ltd. was established in 2011, and is an innovative national high-tech enterprise providing
innovative EMC (electromagnetic compatibility) grounding elastomers and customized tape solutions for the electronics indus

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,Express Delivery,DAF,DES;
Accepted Payment Currency: USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;
Language Spoken: English,Chinese
